Product Specifications
| Model | Edge Crush Tester |
| Motor: | 0.5 HP, 3-phase (Crompton/Bharat Bijlee make) with gearbox |
| Power: | 220 VAC, single phase, 50 Hz |
| Display: | Backlit LCD with measuring units in kgf |
| Accuracy: | ± 1% |
| Capacity: | 100 Kgf |
| Fixtures: | For Ring Crush, Flat Crush, and Edge Crush tests |
| Material: | Powder-coated M.S and hard chromed components |
| Test Speed: | 12.5 mm/min |
| Least Count: | 0.02 kgf |
| Platen Size: | 150 mm diameter (upper and lower) |
| Speed Drive: | Crompton/Delta make |
| Speed Range: | 10 mm/min to 50 mm/min |
| Standards Compliance: | IS 7063-2, TAPPI T 811/T 812, ISO 3037, ASTM D4726, BS EN ISO 3037 |
Product Description
Edge crush tester with 100 Kgf capacity and ±1% accuracy. Features a backlit LCD, 150mm diameter platens, and compliance with multiple international standards. Variable speed drive from 10-50mm/min.
