ANCA MX5 Linear Grinding Machine
₹ 49,900
Brand: ANCA
Anca Machine Tools Private Limited
Verified Supplier
Location
Bengaluru, Karnataka
GST No.
29AAKCA3479J1Z4
Total Products
3+ Products
Secure
Fast Delivery
Easy Returns
Quality
1
| Model | MX5 |
| Auto Stick | 1 to 4 Sticks (option) |
| Micro Plus | Option |
| Loader Type | FastLoad-MX (option) RoboMate (option) |
| Tool length | 300 mm |
| Wheel Packs | 2 x 203 mm (8 Inch ) max |
| Touch Screen | Yes |
| Linear Scales | Standard |
| Pop Up Steady | Option |
| Spindle Power | 26 kW (35 HP) peak 14 kW (19 HP) S1 |
| Tool Load Time | FastLoad-MX 24 sec RoboMate 15 sec |
| Manual Tailstock | Option |
| Overhead Top Clamp | Option |
| Spindle Orientation | Yes |
| Loader Tool Capacity | Fast Load-MX 245 x 3 mm 156 x 6 mm 42 x 16 mm Robo Mate 2520 x 3mm 1560 x 6 mm 462 x 16 |
| Automatic Wheel Probe | Option |
| Maximum Tool Diameter | 200 mm |
| Pneumatic Collet Actuator | Yes |
| Headstock Mounted Coolant Outlet | Yes |
| View Semi Automatic Tool Inspection | Option |
ANCA MX5 linear machine with 203 mm wheel packs. Features standard linear scales, optional auto stick and loaders. Spindle power is 26 kW peak, with 300 mm tool length capacity.
