Tri-Angle Touch Screen Gloss Meter

₹ 9,900
Brand: Others
PACORR TESTING INSTRUMENTS PRIVATE LIMITED
Verified Supplier
Location
Ghaziabad, Uttar Pradesh
GST No.
09AAKCP5615P1ZP
Total Products
57+ Products
Secure
Fast Delivery
Easy Returns
Quality
1

Product Specifications

mode1000
ModalGloss Meter - Tri Angle Touch Screen
Errors±1.5 , ± 1.5%
Weight350g
Battery3200mAh Li-ion Battery ,>10000 times(within 8 hours)
DisplayTFT 3.5 inch
StorageBasic
Humidity<85% relative humidity, no condensation
LanguageEnglish
SoftwareGQC6 Quality Control Software with QC report printing functions and more extended functions.
InterfaceUSB/RS-232
Repeatability± 0.1GU ± 0.2GU ± 0.2%GU
Division Value0.1GU
Measuring Time0.1s
Measuring Angle20°/60°/85° Comply with standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457
Measuring Range20°:0~1000GU 60°:0~1000GU 85°:0~160GU
Reproducibility± 0.2GU ± 0.5GU ± 0.5%GU
Dimension: L*W*H160mm*75mm*90mm
Measurement Range0-10GU 10-100GU 100-1000GU
Measuring Area (mm)20°: 10×10 60°: 9×15 85°: 5×36
Storage Temperature-20~50℃(-4~122°F)
Measurement StandardConform with JJG696 first class gloss meter working requirement
Standard AccessoriesPower Adapter, USB cable, User Manual, GQC6 software CD (except HG60S), Calibration Plate
Operation Temperature0~40℃(32~104°F)
Chromaticity CorrespondingCorresponding with CIE 1931(2°) under CIE C light source

Product Description

Features 3.5-inch TFT display, 3200mAh battery for >10000 measurements. Operates 0-40°C. Storage -20-50°C. Measures 0-1000 GU at 20°/60°/85°. 0.1s measurement time.
