| Drive | 7.5 HP DC motor |
| Capacity | 15 ton |
| Mold width | 152 mm |
| Inclination | 13 Degree |
| Casting Rate | 15 tons per hour |
| Ingot weight | 25 kg +/- 5% each |
| Max Temperature | 500-1000 degree Celsius |
| Mold attachment | By bolting in to conveyor chain |
| Number of molds | 150 |
| Knock out hammer | Two no knockout hammer shall be provided |
| Speed of Conveyor | 3 RPM max/ 1 RPM min |
| Material to be cast | Lead and its alloy |
| Weight of each mold | 40 kg approx |
| Width of the machine | 1.5 meter approx |
| Length of the machine | 12 meter approx |
| Minimum Order Quantity | 1 Unit |
| Centre to centre mold distance | 160 mm |
Lead and alloy casting machine with 15 tons/hr capacity. Features 7.5 HP DC motor, 150 molds, and 13-degree inclination.
